touch operation screen 380v 50hz screw compressor details
| model | SH15 | SH20 | SH30 | SH40 | SH120 | SH150 | SH175 | |
| air delivery | pressure(m³/min)/mpa | 1.65/0.8 | 2.2/0.8 | 3.6/0.8 | 5.0/0.8 | 15.8/0.8 | 20/0.8 | 24/0.8 |
| 1.3/1.0 | 2.1/1.0 | 3.2/1.0 | 4.5/1.0 | 13.8/1.0 | 17.4/1.0 | 20/1.0 | ||
| 1.1/1.25 | 1.9/1.25 | 2.7/1.25 | 4.0/1.25 | 12.3/1.25 | 14.8/1.25 | 17.4/1.25 | ||
| ambient temperature | ℃ | -5～+45 | -5～+45 | -5～+45 | -5～+45 | -5～+45 | -5～+45 | -5～+45 |
| cooling method | air cooling | air cooling | air cooling | air cooling | air cooling | air cooling | air cooling | |
| exhaust air temperature | ℃ | ambient temp +15℃ | ambient temp +15℃ | ambient temp +15℃ | ambient temp +15℃ | ambient temp +15℃ | ambient temp +15℃ | ambient temp +15℃ |
| oil volume | L | 14 | 14 | 30 | 30 | 60 | 80 | 80 |
| noiselevel | Db(A) | 68±2 | 68±2 | 70±2 | 74±2 | 82±2 | 86±2 | 86±2 |
| driving method | direct driven | direct driven | direct driven | direct driven | direct driven | direct driven | direct driven | |
| voltage/frequency | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | |
| power | KW | 11 | 15 | 22 | 30 | 90 | 110 | 132 |
| starting method | Y-△ | Y-△ | Y-△ | Y-△ | Y-△ | Y-△ | Y-△ | |
| size（L*W*H） | mm | 1060*720*1005 | 1060*720*1005 | 1210*820*1160 | 1360*980*1270 | 1750*1230*1560 | 2400*1470*1840 | 2400*1470*1840 |
| weight | kg | 290 | 320 | 470 | 520 | 1480 | 1770 | 1950 |
| outlet | inch | G3/4 | G3/4 | G1 | G1,1/2 | G2 | G2,1/2 | G2,1/2 |
We possess advanced air compressor production equipment and a complete production line. From raw material procurement, parts processing, machine assembly to machine performance testing, we implement strict quality control procedures throughout the entire production process.
The touch operation screen 380v 50 Hz screw compressor is a top-notch air compressor for industrial and commercial use. Its oil tank capacity ranges from 14 to 80 litres. The compressor’s power output, which ranges from 11 to 132 KW, enables it to operate at high efficiency levels. This compressor is an excellent alternative for businesses in need of a quiet and efficient air compressor due of its operating noise range of 68 to 86 db.
It weighs between 290 and 1950 kg, making it portable for people who need to move it around their facility or bring it with them to various job sites. Compressor’s touch operation screen, which offers customers a user-friendly interface for managing the compressor, is one of its important characteristics. The screen enables users to simply change settings and manage the compressor’s operation while providing real-time information on the functioning of the compressor. Equipped with high temperature and pressure protection, motor overload, phase unbalance, plus 13more protections.
The oil-injected compressor system aids in decreasing internal component wear and tear, hence prolonging compressor lifespan and lowering maintenance costs. This Screw Compressor is not only very effective, but it is also long-lasting. The compressor is made of top-notch components and built to survive tough industrial settings. This makes it the perfect option for companies that want a dependable and robust air compressor. For any company wishing to increase its capacity for air compression, this compressor is a superb investment because to its potent performance, user-friendly interface, and sturdy design.
Our air compressors are distributed globally, exported to over 100 countries and regions, and we maintain long-term, stable cooperative relationships. We provide annual training for our global agents and after-sales engineers to ensure they are familiar with new products, technologies, materials, and processes.
contact us and Purchase touch operation screen 380v 50hz screw compressor
China air compressor manufacturer
Professional customization touch operation screen 380v 50hz screw compressor
We specialize in the research, design, and production of a series of piston and screw air compressors. We can supply 5,000 units per month, with a minimum order quantity of only 1 unit, allowing you to easily obtain air compressors that meet your business needs.
Products will be shipped via reliable logistics companies and delivered to your provided address as soon as possible. Shipping costs will be calculated based on the destination and product weight. We will provide customers with a tracking number so you can track the shipment status.
We have passed ISO 9001:2015, ISO 14001:2015, and IATF16949:2016 certifications. Most products have passed CE, RoHS, TUV, 3C, CNAS, and CQC certifications from authoritative organizations.
